Specifications
•Accuracy of ullage, interface detection: ± 2 mm
•Indication of level divided by ullage and interface: Visible and Audible
•Tape length: 15 m / 30 m / 40 m
•Tape graduation: Metric
•Tape resolution: 1 mm
•Diameter of probe: 34 mm
•Minimum detectable level: 8 mm
•Ambient temperature range: -20 °C to 50 °C
•Temperature sensor measurement range: -20 °C to 90 °C
•Temperature measurement resolution: 0.1 °C
•Accuracy over calibration range: ± 0.1 °C ( 0 °C to 60 °C )
•Temperature reading mode: °C (Celsius) or °F
•LCD display: 4- 7 Segment
•Top Coupling (Connection): PF 2-1/4″ TAP
Weight:
•TFC-02 7.4 kg / 15m
•TFS-01 6.4 kg / 30m
Overall dimensions (H X W X T):
•TFC-02 APP. 585 X 346 X 150 mm
•TFS-01 APP. 607 X 297 X 140 mm
Battery: 9 Volt ( Model : MN1604)
Intrinsically safe: type Ex ia IIB T4
