X-MIST- SYSTEM extinguishes or controls fires by cooling, oxygen displacement by water vapor and radiant heat attenuation. The exceptional cooling effect of water mist is a result of the division of water into very fine droplets, which increase the total surface area available to absorb heat and maximizes the evaporation rate of the water.
|
Nozzle type |
ELL |
LL |
HL |
|
Width |
3.0 |
3.0 |
3.0 |
|
Height(m) |
0.5~8.0 |
1.5~4.0 |
4.0~13.5 |
|
Pressure(bar) |
9~12 |
7~10 |
8~11 |
|
Flow(Lpm) |
33~38 |
15~18 |
14~17 |
|
K-Factor |
11.0 |
5.6 |
5.0 |
