SPECIFICATION
Accuracy of ullage, interface detection ± 2 mm
Indication of level divided by ullage and interface Visible and Audible
Tape length 15 m / 30 m / 40 m
Tape graduation Metric
Tape resolution 1 mm
Diameter of probe 34mm
Minimum detectable level 8 mm
Ambient temperature range – 20°C to 70°C
Temperature sensor measurement range – 20°C to 110°C
Temperature measurement resolution 0.1°C
Accuracy over calibration range ± 0.1°C ( 0ºC to 60°C )
Temperature reading mode °C(Celsius) or °F
LCD display 4~7 Segment
Top Coupling(Connection) PF 2- 1/4″ TAP
Weight (TFC-02)
Weight (TFS-01) 7.4 kg / 15m
6.4 kg / 30m
Overall dimensions (H X W X T) TFC-02
Overall dimensions (H X W X T) TFS-01
APP. 585 X 346X 150 mm
APP. 607 X 297X 140 mm
Battery 9 Volt ( Model : MN1604)
Intrinsically safe type Ex ia IIB T4
